Expert Printed Circuit Board Design for Demanding Applications

We have been doing advanced Printed Circuit Board (PCB) design since 2002 – That vast experience at the initial PCB design and layout stage can reduce industry compliance testing issues later on.

Custom PCB design services and PCBA designs are at the heart of every project at DE Design Works. We have created PCB control systems in a lot of product areas including:

• Analog Systems and Sensors

• High Speed Digital and Networking

• Wireless Connectivity such as BLE, Wi-Fi, and LoRa

• EMC / EMI or RFI

• Low Power and Battery Operated

• Industrial Controls and IIoT

• Power Systems

• Motor Control

• Radio Frequency (RF)

• UI/UX, and Touch Screens

• Military

• Medical

• Commercial Products and Appliances

• Broad Market Industrial

Our PCB design to production-ready experience can shorten your product development timeline and save your NRE budget.

Drop us an email at info@dedesignworks.com to tell us about your project, or call us at 314-736-4224.

For more than 20 years, DE Design Works has been in the business of Product Design. We have a professional design process in place for the development of hardware, firmware, testing, and prototype production. This includes a proven management process, an in-house team focused on advanced technology design efforts, and an efficient and realistic management team leading expectations built on experience. Our team has an aptitude for communicating the voice of the customer and delivering a design that meets the goals of the vision for the product. We have a low overhead, a highly technical workforce, an efficient and effective work environment, a state-of-the-art R&D lab, and a full tool set enabling efficient collaboration with customers, vendors, and partners to provide an echo system to support a complete turn-key successful and effective vertical napkin sketch to production product development journey.

Product design is hard, right? We help make it easier. The result is a collaborative learning experience for our business and yours. If you are an original equipment manufacturer (OEM) in any market - let DE Design Works be the missing part of your team to help guide and fill technical expert gaps in your workforce. We will successfully guide you through the landscape of pitfalls and rabbit holes that so many companies fall into along the journey of crossing the chasm into production.

Industrial Product Development: With years of hands-on experience in designing and optimizing cutting-edge industrial products, our team of engineering experts employs a systematic, analytical approach to deliver highly efficient, reliable, and scalable solutions tailored to your unique requirements.

• Industrial Product Development

Medical and Military: Our extensive knowledge in developing medical and military-grade electronics is backed by an unwavering commitment to precision, compliance, and robustness. We meticulously analyze and address the challenges and stringent demands of these critical sectors, ensuring performance and reliability in even the most demanding environments.

• Medical
• Military

Examples of work include:

• IoT electric vehicle charging breaker for mass-market
• connected aspiration pump for vascular surgeons and stroke patients with unique and patented features
• remote monitoring sensor for pumps using LoRa wireless to create an extreme low power, battery operated system
• 3kW military submersible uninterruptable universal DC and AC power supply
• fire truck automation control system operated remotely with rugged mobile tablet
• EEG wearable device
• master clock network server for high precision timing synchronization down to 1 microsecond
• laser marking system with high-speed gyro mirror control and graphics processing
• torque tools and calibration instruments for rugged precision automotive assembly
• drone mounted imaging controls for agricultural application
• servo motor controls for robotic AGVs
• HVAC controller system for commercial and residential
• LED lighting that is wirelessly connected and color tunable
• connected and automated furniture system
• BLDC fuel injector control for performance aftermarket automotive
• secure smart phone credit card reader
• RF ablation surgical platform
• optical tomography device with high-speed spectral analysis

DE Design Works has developed many products for medical, industrial, commercial, automotive, and military OEMs. For our customers, these many experiences help achieve product design goals and reduce industry compliance testing issues at the initial design level.

DE System on Module Case Study

A DE custom system on module (SoM) is an incredibly flexible, rugged, encrypted, low-power platform board was developed for a customer in partnership. The platform features a right-sized Linux ARM processor with automotive-grade thermal capabilities, a field updateable FPGA for ultimate hardware interface flexibility, a dedicated encryption engine for secure speed without compromise. Think of this as a very secure and flexible universal platform in a very small (2” x 3”), low-power package.

Portable CBRN Control System Case Study

As a non-traditional military supplier, we improved the previous generation of mechanical dials and switches in a heavy metal box to include a much smaller and portable size. Reliability in the field was also an issue in previous generations. But this product now contains easy to set and read digital displays in a light-weight total package that still meets the rugged MIL-STD-461 on radiated emissions (a high-level military standard to minimize radiated electronic noise).
